Mouvex API 674

Mouvex

Mouvex, part of PSG, was founded in 1906 and is a leading global manufacturer of positive displacement pumps and compressors for the transfer of liquids and dry bulk products. Mouvex has a very extensive range of positive displacement pumps of various types. Roodhart is the exclusive Benelux distributor for the Mouvex API 674 triplex plunger pump according to API 674.



API 674 / ISO 13710

API 674 is the API standard with regard to reciprocating positive displcament pumps and contains design criteria for both direct-acting pumps and pumps with an electric drive (pumps driven by a motor via a crankshaft). The standard defines topics such as maximum and minimum speeds, pulsation and vibration control requirements, and test requirements.

Applications

Mouvex offers a wide range of API 674 / ISO 13710 triplex plunger pumps available in many configurations to meet all requirements. Many Mouvex API 674 are used in the oil and gas sector, but also in the energy sector and for hydraulic test systems, these pumps are extremely suitable due to the high differential pressures that can be achieved.

Mouvex API 674 product range

Mouvex TD18

Maximum flowrate 5.5 m3 / hr
Maximum pressure 900 bar
Power 13.2 kW.
Viscosity 100 cSt
API speed rating 490 rpm
Mouvex TD18 datasheet



Mouvex NF50

Maximum flowrate 10 m3 / hr
Maximum pressure 900 bar
Power 36.7 kW.
Viscosity 100 cSt
API speed rating 432 rpm
Mouvex NF50 datasheet



Mouvex NJ116

Maximum flowrate 25 m3 / hr
Maximum pressure 900 bar
Power 85.2 kW.
Viscosity 100 cSt
API speed rating 396 rpm
Mouvex NJ116 datasheet



Mouvex NL171

Maximum flowrate 33 m3 / hr
Maximale verschildruk 900 bar
Vermogen 125.6 kW.
Viscositeit 100 cSt
API speed rating n.v.t.
Mouvex NL171 datasheet



Mouvex TN260

Maximum flowrate 82 m3 / hr
Maximum pressure 938 bar
Power 191 kW.
Viscosity 100 cSt
API speed rating 312 rpm
Mouvex TN260 datasheet



Mouvex TP420

Maximum flowrate 108 m3 / hr
Maximum pressure 866 bar
Power 310 kW.
Viscosity 100 cSt
API speed rating 250 rpm
Mouvex TP420 datasheet
